CPS Standard on Nutanix Released

nutanixCPS
Fun and crazy days here at Nutanix. I’ve busy been fielding a lot of calls around our new offering, CPS Standard on Nutanix. Now if you don’t know what CPS is, it stands for Cloud Platform System.

So what is Microsoft CPS anyways?

Simply, Microsoft CPS is a software stack of Window Server, System Center, and Windows Azure Pack.  CPS delivers a self-service cloud environment for Windows and Linux applications that provides optimized deployment of Windows Azure Pack.
Currently based on Windows Server 2012 R2, System Center 2012 R2 and Windows Azure Pack, CPS provides an Azure-consistent experience by leveraging Azure services to deliver business continuity (through Azure Site Recovery) of your hybrid cloud for your virtualized Windows and Linux workloads. For more details on Windows Azure Pack, check out my blog series on WAP.

If you have read my WAP blog series, building your own cloud can be a complex undertaking. Integrating the hardware, installing and configuring the software, and optimizing the overall solution for usability, performance, and scale, and reliability means that many cloud deployments fall short.

Introducing Microsoft CPS on Nutanix, an easier way to deploy WAP

The solution is due to the co-engineering and joint validation efforts with Microsoft and Nutanix. Getting the solution up and running is pretty fast, accelerating your time to value.
The joint effort goes beyond initial deployment. Once the Microsoft\Nutanix CPS solution is up and running, you get a single point of contact for support and simplified patching and updating across the entire stack of firmware and software. And as an added benefit, you get the ability to scale the environment with all the Nutanix goodness.

Bits are installed at the factory, so when you get your Nutanix Block, it’s just as easy as a wizard to get you up and running.  Below is a video that my buddy @mcghee did on the install and initial configuration of CPS. The video brings you right up to the admin and tenant portals and gives you a brief tour.

Enjoy…Until next time, Rob….

Microsoft Exchange Best Practices on Nutanix

To continue on my last blog post on Exchange...

As I mentioned previously, I support SE’s from all over the world. And again today, I got asked what are the best practices for running Exchange on Nutanix. Funny enough, this question comes in quite often.  Well, I am going to help resolve that. There’s a lot of great info out there, especially from my friend Josh Odgers, which has been leading the charge on this for a long time.  Some of his posts can be controversial, but truth is always there.  He’s getting a point across.

This blog post will be updated on a regular basis as things change. It will also be moved to a permanent part of the netwatch.me resources section.  This is meant to be a general best practice guide to help with planning and maintaining a healthy Exchange environment on Nutanix.  I will specify hypervisor specifics when required.  Now on the post…..

msexchange.

Let’s start out with the basics…

MS Exchange on Nutanix Support

Nutanix provides a 100% supported solution for MS Exchange running on vSphere, Hyper-V or Acropolis Hypervisor using iSCSI (Block storage)
Here is a breakdown of supported configurations by hypervisor:

vSphere (ESXi) Use In-Guest iSCSI (Volume Groups) for full support
Hyper-V Use SMB 3.0
AHV Use native vDisks (iSCSI) – SVVP Certification for AHV

Also, check out Josh’s post “Fight the FUD – Support for MS Exchange on Nutanix” that outlines this very topic.  In summary, the customer has the choice to deploy in multiple configurations to suit their needs. But, one of the most often questions I get is, “does your SVVP Certification cover running Exchange on all your supported hypervisors?”  The answer is not simple.  The SVVP was submitted for the Acropolis Hypervisor, while this does not cover all of them, we technically are supported for all hypervisors as per Microsoft supported storage architectures.  Microsoft does not specifically mention Hyperconverged, it only mentions ISCSI in regards to SAN.  IMO, that covers ESXi and AHV.

Now let me explain….SAN’s are one of the biggest modern datacenter bottlenecks. Data has gravity, so co-locating storage and compute eliminates network bottlenecks = Hyperconverged is way better than SAN and hence SUPPORTED IMO 😉

To end this topic and move on, a Nutanix customer has the choice to deploy in multiple configurations to suit their needs.  Being pushed to one particular hypervisor for a customer is not always in their best interest.  Having choices now and later is a much better approach with the overall goal of simplifying the datacenter.   As Josh said in one of his blog posts ,”Running a standard platform and storage protocol for all workloads is a simple model which reduces the unnecessary complexity of multiple protocols and/or in-guest storage configurations”, I can’t agree more with that statement. 🙂

Exchange Performance on Nutanix

Now this subject will always be controversial and potentially subject to criticism.  Internal testing performed by the Nutanix Performace and Engineering team shows that AHV and Hyper-V performance are roughly the same from a hypervisor perspective and ESXi was 10% higher. That being said, usually, the next question is how is performance versus traditional SAN/NAS.  And again, I have to point out, it’s all about Data Locality. Can’t change the laws of physics. Data has gravity, hence we will always beat traditional SAN architecture.

Check out Josh’s posts on “Peak Performance vs Real World – Exchange on Nutanix Acropolis Hypervisor”.  It gives you a better understanding of are realistic benchmarks of Exchange in general and on Nutanix. I wholeheartedly agree with Josh when he says “Benchmarks are of little value without context specific to customer requirements!”  Spending close to over 15 years building and maintain Exchange systems, I learned one hard fact, no generic simulator (like JetStress) can show real world metrics.

Data Reduction Technologies with Exchange on Nutanix

Recommendation:
1 vDisk per Database, 1 vDisk per DB Logs
1 Container with RF2, In-Line Compression & EC-X for Databases
1 Container with RF2 for Logs
Do not use Dedupe with MS Exchange!
Reference: https://technet.microsoft.com/en-us/library/ee832792(v=exchg.150).aspx
Microsoft does not support Data deduplication (Note: Underlying storage deduplication such as Nutanix dedupe is not mentioned, but implied)

Data Reduction Estimates:

Rule of thumb: Always size without data reduction if possible.
Conservative assumption for compression for Exchange = 1.3:1
Aggressive assumption for compression for Exchange = 1.6:1
Conservative assumption for EC-X for Exchange = 1.1:1
Aggressive assumption for EC-X for Exchange = 1.25:1

Questions to ask yourself when planning an Exchange Environment:

How many Users? e.g.: 10000, 10000, etc.
How many user profiles do you need? e.g.: 2 , Standard and Executives
How large Mailbox (excluding archiving) per User? e.g.: 1GB, 2GB , 5GB
How many messages per day do you want to support per user? Light = 50 , Medium = 100 , Heavy = 150+

Do you require site resiliency?

These are among some of the basic questions you need to answer.  This is where the Exchange Server Role Calculator comes in. It’s a great tool, but like any tool, you do need to give it good input to get out good output. The function of the tool is as the name implies.

Exchange Server Role Calculator Defined

Now, at the time of this writing, version 7.8 is the latest and greatest. Now, do note, I would not call this tool perfect, but its gets you pretty close. Like anything else, the Exchange team is still learning real world behavior and this is where a good experienced Exchange engineer comes into play.

IMO..there is an Art and Science to sizing Exchange.  The days of Exchange just being a simple mail server are far over. These days, it’s much more complex with supporting multiple forms of ingress and egress traffic for different functions (Mobile, Web, SMTP, Skype Integration, etc.). Each of these different functions has varying load considerations and supports more visible features like Outlook Web Access and Exchange Activesync. Also, I still am of the opinion that it does not take into consideration the number of devices that 1 mailbox services.
exchangecomplex
Considering this complexity, you can see that undersizing or oversizing can happen easily.  If you size correctly at the beginning with Nutanix, then it just an easy scale out, buy as you need it situation. Then you know what happens, finally for the first time, predictability in your budgets.  I remember the days, not that long ago, when I had to have a client retire a SAN, not for space constraints, but for IO constraints.  And at the time, all I got from the client was “can’t we use it for something else” and ya, I’ve replied with “use it as a WSUS repository for patching the Exchange environment” 😉

During my next post, I will dive into the Exchange Role Calculator much more and go over some examples of sizing on Exchange. We’ll mainly focus on mailbox storage and then move on to other role sizing considerations.  I also plan to cover the other aspects to maintain a healthy Exchange environment (i.e. Message Hygiene, Global and Local Load balancing, Integrations and End User Experience) in subsequent posts.
Below are the Office Best Practices Guides from Nutanix and some public case studies.

Until next time, Rob…..

Nutanix Offical Best Practice Guides
MS Exchange on Nutanix / vSphere Best practice guide: http://go.nutanix.com/VirtualizingMicrosoftExchangeonWeb-ScaleConvergedInfrastructure.html

Public Case Studies for Nutanix customers using Exchange
Richter: http://go.nutanix.com/rs/nutanix/images/Nutanix-Case-Study-Richter.pdf
Riverside: http://www.nutanix.com/resource/riverside-for-riversides-server-and-storage-consolidation-nutanix-fits-like-a-glove/

Nutanix NOS 4.6 Released….

On February 16, 2016, Nutanix announced the Acropolis NOS 4.6 release and last week was available for download. Along with many enhancements, I wanted to highlight several items, including some tech preview features.
Also, checkout this excellent video with Nutanix’s Tim Isaacs and Raghu Nandan in which they go into more detail on the updates included in Acropolis 4.6 and the interviewer is my buddy Chris Brown.
Tim Isaacs and Raghu Nandan from Nutanix HQ about some of the important updates in Acropolis 4.6.

1-Click Upgrades – BIOS and BMC Firmware
The 1-Click upgrade for BIOS and BMC firmware feature is available for Acropolis hypervisor (AHV) and ESXi hypervisor host environments running on NX-xxxx G4 (Haswell) platforms only.
Acropolis App Mobility Fabric: Windows or Linux Guest Customization
Customize or clone Windows or Linux guest VMs hosted by AHV. Includes automated OS installation and custom ISOs by using sysprep (Windows) or cloudinit (Linux).
Acropolis Drivers for OpenStack
These drivers facilitate consuming the Nutanix Acropolis infrastructure as a cloud service or for use in a data center. For example, an OpenStack implementation might require using features such as single sign-on, orchestration, role-based access control, and so on. Drivers include Acropolis compute, image, volume, and network drivers.
Convert Cluster Redundancy Factor from RF-2 to RF-3
Convert a cluster created with redundancy factor 2 (RF-2) to RF-3 through the ncli cluster set-redundancy-state command. This increases the cluster fault tolerance.
Cross Hypervisor Disaster Recovery
Cross-hypervisor disaster recovery provides an ability to migrate the VMs from one hypervisor to another (ESXi to AHV or AHV to ESXi) by using the protection domain semantics of protecting VMs, taking snapshots, replicating the snapshots, and then recovering the VMs from the snapshots. To perform these operations, you need to install and configure NGT on all VMs.
Guest VM VLAN Trunking
AHV supports guest VM VLAN tagging, where the tag passes through a single port from the physical network to a VM. It allows the VLAN ID tags to be included in an Ethernet packet to be passed to the guest VM. Guest VM operating systems can use this feature to enable Virtual Guest Tagging (VGT) and simulate multiple virtual NICs.
More Backup and Data Recovery/Replication Features

  • Snapshot and Async DR for volume groups.
  • Application-consistent snapshots on AHV and ESXi by using the Nutanix native in-guest Volume Shadow Copy Service (VSS) agent for all VMs that support Microsoft’s VSS. Nutanix Guest Tools provides application-consistent snapshot support for Linux VMs by running specific pre-freeze and post-thaw scripts on VM quiesce.
  • Integrated snapshot management from an AHV cluster to a CommVault solution

Nutanix Guest Tools

  • Nutanix Guest Agent (NGA) service. Communicates with the Nutanix Controller VM.
  • File Level Restore (FLR) CLI. Performs self-service file-level recovery from the VM snapshots.
  • Nutanix VM Mobility Drivers. Facilitates distribution of drivers required for VM migration between ESXi and AHV, in-place hypervisor conversion, and cross-hypervisor disaster recovery (CH-DR) features.
  • VSS requestor and hardware provider for Windows VMs. Enables application-consistent snapshots of AHV or ESXi Windows VMs.
  • Application-consistent snapshot for Linux VMs. Supports application-consistent snapshots for Linux VMs by running specific scripts on VM quiesce.

Self-Service Restore
Self-service restore allows a user to restore a file within a virtual machine from the Nutanix protected snapshot with minimal Nutanix administrator intervention. This feature is supported on Nutanix clusters running the ESXi and Acropolis hypervisors only.

Tech Preview Features
In-Place Hypervisor Conversion
This 1-click feature available through the Prism web console allows you to convert your cluster from using ESXi hosts to using AHV hosts. Guest VMs are converted to the hypervisor target format, and cluster network configurations are stored and then restored as part of the conversion process.
Native File Services
Provides file server capability within a Nutanix AHV cluster, as one or more network-attached VMs, to form a virtual file server.
To download the update, you can go to my.nutanix.com and go to support, downloads section or you can upgrade to 4.6 within Prism.  Until next time, Rob

A Tale of Two DAGs – Deploying Exchange 2013 DAG Environment on Nutanix

As always, I try to blog on questions I get from the field and recently, I helped some colleagues and customers build a DAG on Nutanix 2 times last week ;).  The process is pretty straightforward, but there are some best practices that everyone should follow to ensure a healthy DAG environment.

Creating a two node Microsoft Exchange 2013 Database Availability Group

Introduction

Ok, let me tell you how to make your Exchange 2013 Mailbox role deployment highly available (HA) by using a Database Availability Group (DAG).. Let’s get rocking’.

Before we get too deep into it, let’s first make sure you’re on the right plane. This flight will take you through configuring a DAG in Exchange 2013 with two nodes in the same site to make your Mailbox role highly available. In a later blog post I will be covering how to make your Exchange 2013 Mailbox role deployment site resilient by adding additional nodes in a remote location. If you’re still with me, buckle your seatbelt and keep your hands inside the cabin at all times.

Server Safety Check

Before we can take off, we need to do a pre-check routine on all our servers because the last thing we want is to get cruising at 20,000 users and then have it crash. Let’s discuss the operating system requirements.

Operating System

DAGs utilize Windows Failover Clustering so you’re going to need a Windows OS that supports that and since Exchange 2013 can only be installed on Server 2012 and Server 2008 R2 SP1, we’ll focus on those. If you’re running 2008 R2, you’ll want Enterprise or Datacenter. If you’re running Server 2012, you can use Standard or Datacenter. There’s nothing worse than installing Exchange only to find that you put the wrong OS on there when you go to configure the DAG. I have seen this happen many times at customers. Just in case you’re wondering, Microsoft does not support upgrading the OS once Exchange has been installed so your only option is to uninstall Exchange, install the correct OS, and then reinstall Exchange or build a new server with the correct OS. After you’ve got the correct OS, you’ll want to install the most current updates.

The Network

DAGs need to replicate and clients need to connect, so it’s only natural that you’d need two NICs to create a DAG. Microsoft supports a single NIC but it’s recommended you use two so you can separate the replication traffic from the client traffic. You don’t want the reseeding of a database to affect your users’ experience. Let’s talk about the two NICs real quick. The first thing I like to do is name them appropriately. I usually name my replication NIC REPL and my client NIC MAPI, that way there’s no confusion in this next step I take, and that’s to put them in the correct binding order.
DAG-ConfigServerNetwork
The MAPI NIC needs to be listed first. This is how you do that.

  1. From the command prompt, type in NCPA.CPL to open up the Network Connections screen.
  2. Press the Alt key and that will display the File menu, then click on Advanced and select Advanced Settings…
  3. On the Adapters and Bindings tab, order the adapters so that MAPI is first and REPL is second.

Note: If you’re using network teaming, ensure the MAPI team is listed first and the REPL team is listed second.
DAG-ConfigServerNetwork1
Quick note about Network Teaming. I’m a fan of it because I don’t want a NIC failure to cause a database failover. NIC teaming is supported on client and replication networks but you have to configure each team so that only one NIC in the team is up and the other NIC is in standby, which means Active/Passive.

Last thing I want to point out is the IPv6 check box on each NIC. Everywhere I go I see admins – this box because they don’t “support” IPv6. First point is, unchecking that box doesn’t truly disable IPv6. Second point is, if you’re having issues with Exchange connectivity, chances are having the check box checked is not your issue. Lastly, Microsoft does not test Exchange with that box unchecked, so technically you’re in an unsupported configuration by unchecking it. All that was said to say, leave it alone even though you really, really want to uncheck it.

Client Network

This is the king of NICs because it gets it all, default gateways, DNS settings, and priority, and there can only be one! You’ll configure this just like you would any other NIC card for a server.

Replication Network

The replication network needs to be on a different subnet than the client network or the DAG won’t see them as two separate networks, obviously. For this post, I used 10.1.1.0/24 for my MAPI network and 192.168.1.0/24 for my replication network. If you have a separate network for backups or administration, I would use that. I wouldn’t create a dedicated network just for Exchange replication unless you have to. DAG replication networks can share. It learned how to in kindergarten. If you want to use more than one replication network, then each replication network will need to be on different subnets as well. There are a few things you need to do with this network. Let’s go through that because you get to uncheck stuff, just not the IPv6 box

  1. From a command prompt, type in NCPA.CPL to open the Network Connections window
  2. Right-Click the Replication NIC and go to Properties
  3. Uncheck Client for Microsoft Networks and File and Print Sharing for Microsoft Networks
  4. Select IPv4 and click Properties
  5. Input your IP Address and Subnet mask. Do NOT put in a Default Gateway or DNS servers.
  6. Click on Advanced…
  7. Click on the DNS tab and deselect Register this connection’s addresses in DNS
  8. Click on the WINS tab and select Disable NetBIOS over TCP/IP
    Wow that was a lot of steps. Ensure you click Ok to save all that stuff!

Nutanix Best Practices for Exchange Storage

  • Separate database and log files into separate containers
  • Databases should be on a container with in-line compression and EC-X enabled
  • The Windows NTFS Allocation unit size should be set to 64KB for Database Drives
  • Log Files should be on a container with no attributes and located on a volume with 4k block allocation size.
  • Archive Databases should be on a separate container from active databases with In-Line Compression and EC-X enabled

As per Microsoft Best Practices, Nutanix recommends to disable deduplication for the container hosting active Exchange Databases workloads. Deduplication does not provide significant benefits due to frequency of change in the Exchange Databases.
Alright, we’ve got our servers ready for the DAG, now it’s time to install Exchange. If you need help doing that, I’ve will be covering that in a future blog post. If you have Exchange already install, then move on forward.

Creating the DAG

Now the real fun begins! We get to create stuff. Let’s open up the Exchange Admin Center (EAC) and click on Servers –> database availability groups.
DAG-CreatingDAG
As you can see I already have a DAG but don’t worry, I didn’t get started without you. I’m going to create another one cleverly named DAG02. Click on the ‘+’ sign so we can create a new DAG.
DAG-CreatingDAG2
In the new database availability group windows, You’ll give this a name, pick a witness server and give it an IP. Let’s talk about each of those real quick.

DAG Name

This name needs to be unique in the environment because once you join the first server to the DAG, a Cluster Name Object (CNO) will be created in Active Directory with this name. This CNO can be pre-staged, meaning you can create it manually before Exchange does. You might want to do that in scenarios where you don’t have rights to create Computer objects in Active Directory. At the time I’m writing this, Technet states that in Exchange 2013, if you’re DAG members are running 2012 that you have to pre-stage the CNO, but my testing has proven otherwise. Regardless, stay on the safe side and pre-stage the CNO if you’re OS is 2012.

Witness Server

You have to pick a server to host a share for the DAG. This share is only needed when there is an even number of nodes in the DAG, and it’s not utilized until you need it to maintain quorum. I’ll explain that in more detail in my Nerd Knowledge section below. Skip it if you don’t care. If you plan to have an odd number of nodes in your DAG you have to configure it regardless because Exchange will use it to adjust the quorum configuration automatically as you add and remove nodes from your DAG.

The next question is, “Rob, who should I give the honor of being the witness to?” Good question! We’ll, if you are separating your CAS and Mailbox roles out, pick a CAS server. In fact, if you leave the witness server blank and there is a CAS server in that site, Exchange will automatically pick it. If you’re not separating out the roles, then you have to pick a server. A good candidate would be a server that’s not going to be rebooted a lot but I wouldn’t have a dedicated witness server, it’s a waste of resources, so pick an existing file server or a server that’s within your area of control. Before you decide to pick a Domain Controller, review the witness bullet points below.

  • Witness Servers must be in the same forest and not be a member of the DAG.
  • Witness Server must have the Exchange Trusted Subsystem (ETS) group added to the local administrators group. If this is a Domain Controller, it needs to be added to Domain\Administrators. This is why you might want to not pick a domain controller. This gives the ETS administrative rights to the entire domain, not just that server. Granted ETS has crazy rights already, but putting the ETS in the Administrators group for the domain might make your security people nervous.
  • Witness Server must be running Server 2012, Server 2008 R2, Server 2008, Server 2003 R2, or Server 2003.

Few more notes about the Witness server. It does not need to be highly available, meaning don’t put it on a cluster, and a server can serve as the witness server for multiple DAGs but each DAG needs it’s own witness share. Also, you don’t need to specify a path when creating the DAG. Leave it blank and Exchange will create the proper folder structure. Lastly, I’m assuming you’re installing two or more nodes in one physical site. If you plan to put nodes in other sites, then you’ll want to pick a Witness server in the site that holds the majority of your users.

Nerd Knowledge: I mentioned that the Witness server is only used when there is an even number of nodes and only utilized when it’s needed to maintain quorum, and those of you that are nerds like me, I wanted to explain that a little more. Like I mentioned before, a Witness server is only used when there is an even number of nodes in the DAG, but Exchange will want to configure one so that it can automatically adjust the quorum configuration as you add and remove nodes. For example, if you have two nodes, under Failover Cluster Manager you’ll see the quorum configuration set to Node and File Share Majority. If you add a third node, the quorum configuration will change to Node Majority and the Witness server is not used at all.

Now to address the other statement of the Witness server only being utilized to maintain quorum. A DAG must “have quorum” to mount databases and if it loses quorum, you’re environment will go down. To maintain quorum there must be enough votes in the DAG and each server is a voting member. For example, if you have a two node DAG the number of votes to stay up is 2. That can be found by taking the number of nodes in the DAG, dividing it by 2, and then adding 1. In a two node DAG that looks like this (2 nodes / 2) +1 = 2. Again, that means in a two node DAG we need two votes to maintain quorum and keep our databases mounted.

I know what you’re thinking, “But, Rob, we only have two members in our DAG and we need two votes. Doesn’t that mean we can’t lose a server without dismounting all of our databases?” Fair question, young padawan so let me tell you. This is where the Witness server comes into play. In a two node DAG, in normal operation, a Witness server is not used because we don’t need it. We have our two voting members up, but if we lose one of those nodes, the surviving node will try to lock the witness server. If it successfully locks the witness server, it becomes special and gets a second vote, which gives us our two required votes to maintain quorum and life is good. However, if you reboot the witness server in this scenario, you’ll lose quorum and your mailboxes will dismount. Even worse, they won’t mount again until you either “shrink” your DAG, or get both nodes back up. That might sound confusing and I can cover that in another post because the length of this is getting out of control, but just remember that if you have one of your two DAG members down, don’t reboot your witness server or your surviving node.

Wow, that’s a lot, but I need to explain one more example to ensure we fully understand this. Let’s assume we have six nodes in our DAG. To maintain quorum we need four votes (6/2) + 1 = 4. We have an even number of nodes so we need a witness server, but we won’t use it until we need it to maintain quorum. If we lose one or two of the six nodes, we still have enough votes, so right now we don’t need the witness server. If we lose a third node, one of the surviving nodes will try and lock the witness server.

Whoever grabs it first wins and that surviving node gets an extra vote making it 2 +1 +1 = 4. Make sense? I hope so, cause I lost my own attention two paragraphs ago! LOL Let’s move on.

DAG IP Address

This is the IP address used by the DAG. It uses DHCP by leaving it blank or you can specify a static IP address here.

Now that you’ve put in all the information, click Ok. Finally!!
You can now see the DAG in the EAC, and if wanted to be a true nerd, you can open ADSIEDIT and go to

CN=Database Availability Groups,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=<Org Name>,CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=<Domain>,DC=<Com>. You should see the msExchMBDatabaseAvailabilityGroup object.

DAG-CreatingDAG4
You should also check the witness server to ensure the file share was created.

Adding Servers to the DAG

Now that we have an empty DAG and a witness server, we need to add servers to it. This is done by highlighting the DAG in the EAC and clicking the Managed DAG membership.
DAG-CreatingDAG5
On the manage database availability group membership screen, click the ‘+’ sign to add servers to the DAG.
DAG-CreatingDAG6
Select the servers you want to add to the DAG. You can select multiple servers here. I’m adding two servers at the same time. I’m skipping RED-15EXCH02 because it’s running 2008 R2 and the other two servers I’m adding are running 2012.

When you add the first Exchange server to the cluster, that server creates the CNO in Active Directory if you didn’t pre-stage it. Microsoft has reported that if you add Exchange servers to the DAG too quickly and Active Directory does not have time to replicate, the second Exchange server might not see the CNO and then create it’s own. This might be another reason to pre-stage the CNO before adding a node to the DAG or at least make sure you force replication after you add the first node to the DAG to replicate around the CNO.
DAG-CreatingDAG7
Once the servers have been added to the DAG, you should see something like this.
DAG-CreatingDAG8
Now that we’ve created our DAG, we can take a look at it by opening up the Exchange Management Shell (EMS) and running Get-DatabaseAvailabilityGroup DAG02 -Status | FL. That should give you something like this. You can notice a few things from this screenshot. You can see that Compression and Encryption are enabled between DAG members in other sites if we decided to extend this DAG to another location.

Note that it’s a DAG property not a network property so that means it’s either enabled for all networks in the DAG or none of them. Another thing worth noting is the port that the DAG replicates on, 64327. This is helpful when there is a firewall between your Exchange servers.
DAG-CreatingDAG9
Now your screenshot might look a little different than mine because I ran Set-DatabaseAvailabilityGroup DAG02 -DatacenterActivationMode DagOnly. This prevents a split brain cluster from forming, so that makes this setting a must in all DAGs. I highly recommend you set it too.

Lastly, you can see that our witness server is configured and what server is hosting the Primary Active Manager.

Let’s take a quick look at the Failover Cluster Manager to see what happened there.
DAG-CreatingDAG10
From above screenshot, you can see that we have a cluster named after the DAG and our two servers are added as nodes. You can also see that the cluster configuration is Node and File Share Majority. Remember, it’s because we have an even nodes in the cluster. If we added a third node, it would configure the cluster to use Node Majority.

Quick Tip: If you’re worried about your cluster configuration, witness server, or your DAG settings in general, try running Set-DatabaseAvailabilityGroup DAG02 from EMS. That’s right, no parameters. It will make sure you didn’t do anything stupid. I use this like Roy uses, “Have you tried turning it off and on again?” If you don’t know who Roy is and have never heard that phrase, you need to stop reading this post, open a Netflix account, if you don’t already have one, look up “IT Crowd”, watch the “The Speech” episode on Season 3, and come back here and post about how funny it was and how much you want to thank me for telling you about it.

One last thing I’d like to point out here are the DAG networks. If you open up the EMS, and run Get-DatabaseAvailabilityGroupNetwork, you’ll see your DAG networks. Remember that I have two DAGs, but you should see something similar to DAG02’s networks DAG02\MapiDagNetwork and DAG02\ReplicationDagNetwork01. Why did it put a ’01’ at the end of the replication network and not the MAPI network? Because MAPI is the highlander and there can only be one! You can also see which networks are enabled for replication. I’ve noticed that my MAPI network for DAG02 is configured for replication, but I’m going to fix that below.
DAG-CreatingDAG11
In Exchange 2010, you had to configure your DAG networks manually, such as disabling replication on the MAPI network. If you run Get-DatabaseAvailabilityGroupNetwork, you can see that Exchange 2013 auto configured it for us. In fact, if you want to configure the DAG networks manually in Exchange 2013, you have to run Set-DatabaseAvailabilityGroup dag02 -ManualDagNetworkConfiguration $True. I’m going to run this command to disable replication on my MAPI network because the DAG enabled it for me and I want that disabled on that network to force everything through the replication network. This doesn’t meant that the DAG will never use the MAPI network to replicate because in an emergency situation when all replication networks are down, DAG02 will use the MAPI network if it has to so that replication continues. You can run the following command to see which network your DAG is using for replication. Get-MailboxDatabaseCopyStatus -Server red-15exch01 | fl name,incoming,outgoing. Running this from both servers in our DAG will show which network the log copying is coming in on.
DAG-CreatingDAG12

Adding Database Copies

Well done so far! You’ve created a DAG and hopefully learned some stuff. Now that we do have this fancy DAG, we need to use it by creating Database copies. Let’s jump back over to the EAC and click on servers, then databases. One quick thing here. Am I the only one that hates it when menu items aren’t capitalized??? That drives me nuts that the menu options in the EAC are not capitalized, but I’m open to change. We’ll see how that goes. Ok, back on track.

Click on the database hosted by one of the member in our DAG and click on the “…” and select Add database copy. This will “seed” the database, meaning copy over the EDB file over to the server you pick and then copy over the log files. If you’re database is large, it could take some time depending on your bandwidth. If you’re doing this in a lab with an empty database, it should go pretty quick. You’ll want to do this for each database in the DAG that you want protected.DAG-CreatingDAG13
And we’re done!!!
In this post you learned how to create and get started on configuring a DAG. I talked about Nutanix Best Practices around DAG’s.  I talked way too much about the Witness Server.. Man there was a lot in this post, but I truly hoped you learned something even if it’s never to read one of my posts again. :).

As always, I encourage your feedback and any questions you might have..

Until next time, Rob

NPP Training series – How does it work – CVM – Software Defined

To continue NPP training series here is my next topic:  How does it work – CVM – Software Defined

If you missed other parts of my series, check out links below:
Part 1 – NPP Training series – Nutanix Terminology
Part 2 – NPP Training series – Nutanix Terminology
Cluster Architecture with Hyper-V

Data Structure on Nutanix with Hyper-V
I/O Path Overview
Drive Breakdown

To give credit, most of the content was taken from Steve Poitras’s “Nutanix Bible” blog as his content is the most accurate and then I put a Hyper-V lean to it. Also, he just rocks…other than being a Sea Hawks Fan :).

Software-Defined
Nutanix CVM

As mentioned before (likely numerous times), the Nutanix platform is a software-based solution which ships as a bundled software + hardware appliance.  The controller VM or what we call the Nutanix CVM is where the vast majority of the Nutanix software and logic sits and was designed from the beginning to be an extensible and pluggable architecture. A key benefit to being software-defined and not relying upon any hardware offloads or constructs is around extensibility.  As with any product life-cycle, advancements and new features will always be introduced.

By not relying on any custom ASIC/FPGA or hardware capabilities, Nutanix can develop and deploy these new features through a simple software update.  This means that the deployment of a new feature (e.g., deduplication) can be deployed by upgrading the current version of the Nutanix software.  This also allows newer generation features to be deployed on legacy hardware models. For example, say you’re running a workload running an older version of Nutanix software on a prior generation hardware platform (e.g., 2400).  The running software version doesn’t provide deduplication capabilities which your workload could benefit greatly from.  To get these features, you perform a rolling upgrade of the Nutanix software version while the workload is running, and you now have deduplication.  It’s really that easy.

Similar to features, the ability to create new “adapters” or interfaces into Distributed Storage Fabric is another key capability.  When the product first shipped, it solely supported iSCSI for I/O from the hypervisor, this has now grown to include NFS and SMB for Hyper-V.  In the future, there is the ability to create new adapters for various workloads and hypervisors (HDFS, etc.).

And again, all of this can be deployed via a software update. This is contrary to most legacy infrastructures, where a hardware upgrade or software purchase is normally required to get the “latest and greatest” features.  With Nutanix, it’s different. Since all features are deployed in software, they can run on any hardware platform, any hypervisor, and be deployed through simple software upgrades.

The following figure shows a logical representation of what this software-defined controller framework (Nutanix CVM) looks like:Nutanix CVMNext up, NPP Training Series – How does it all work – Disk Balancing

Until next time, Rob…

Exchange Server 2016 RTM Released: Forged in the cloud. Built for Web-Scale

Exchange Server 2016 is here and available to download!!!

What sets this version of Exchange apart from the past, is that it was forged in the cloud. This release brings the Exchange bits that already power millions of Office 365 mailboxes to your on-premises environment. And deploying Exchange 2016 on Nutanix, you can truly create the ultimate email web-scale environment.

Email remains the backbone of business communication and the one that workers consider the most essential tool for getting things done. Because of this, it’s vital to have a modern messaging infrastructure that meets today’s business expectations of scale. With the volume of email and other communications continuing to grow, people need tools that help them focus on what’s most important in their inboxes, schedules and interactions with others at work. And as the quantity of email data grows, so do the demands on IT to manage, preserve and protect it. This is why Web-Scale so important in an Exchange 2016 environment.

Web-Scale Fundamentals
Exchange Server 2016
To help you meet these challenges with Exchange Server, Microsoft has deepened the integration between Exchange and other Office products, so your organization can be more productive and collaborate more effectively. They’ve made it easier to manage your email with new ways to focus on what’s important, work more efficiently, and accomplish more with your devices. Microsoft has also simplified the Exchange architecture and introduced additional recovery features.

Exchange 2016 builds on and improves features introduced in Exchange 2013, including Data Loss Prevention, Managed Availability, automatic recovery from storage failures, and the web-based Exchange admin center.

  • Better collaboration: Exchange 2016 includes a new approach to attachments that simplifies document sharing and eliminates version control headaches. In Outlook 2016 or Outlook on the web, you can now attach a document as a link to SharePoint 2016 (currently in preview) or OneDrive for Business instead of a traditional attachment, providing the benefits of coauthoring and version control.
    Exchange Server 2016
  • Improved Outlook web experience: Continuing our effort to provide you with a first class web experience across devices, Microsoft has made significant updates to Outlook on the web. New features include: Sweep, Pin, Undo, inline reply, a new single-line inbox view, improved HTML rendering, new themes, emojis, and more.
    Exchange Server 2016
  • Search: A lightning-fast search architecture delivers more accurate and complete results. Outlook 2016 is optimized to use the power of the Exchange 2016 back-end to help you find things faster, across old mail and new. Search also gets more intelligent with Search suggestions, People suggestions, search refiners, and the ability to search for events in your Calendar.
    Exchange Server 2016
  • Greater extensibility:  An expanded Add-In model for Outlook desktop and Outlook on the web allows developers to build features right into the Outlook experience. Add-ins can now integrate with UI components in new ways: as highlighted text in the body of a message or meeting, in the right-hand task pane when composing or reading a message or meeting, and as a button or a dropdown option in the Outlook ribbon.
    Exchange Server 2016
  • eDiscovery: Exchange 2016 has a revamped eDiscovery pipeline that is significantly faster and more scalable. Reliability is improved due to a new search architecture that is asynchronous and distributes the work across multiple servers with better fault tolerance. You also have the ability to search, hold and export content from public folders.
  • Simplified architecture: One Role…!  Exchange 2016’s architecture reflects the way we deploy Exchange in Office 365 and is an evolution and refinement of Exchange 2013. A combined mailbox and client access server role makes it easier to plan and scale your on-premises and hybrid deployments. Coexistence with Exchange 2013 is simplified, and namespace planning is easier.
  • High availability: Automated repair improvements such as database divergence detection make Exchange easier than ever to run in a highly available way. Stability and performance enhancements from Office 365, many of which were so useful that Microsoft shipped them in Exchange 2013 Cumulative Updates, are also baked into the product.

That’s just quick list of highlights; I encourage you to get a full view of what’s new by reviewing the Exchange 2016 documentation on TechNet.
Or, if you are in the mood for something more bite-sized, check out these short demo videos in which a few members of the Exchange team show off their favorite features:

Exchange 2016 will follow the same servicing rhythm as Exchange 2013, with Cumulative Updates (CUs) released approximately every three months that contain bug fixes, product refinements, and selected new investments from Office 365. The first CU is expected to arrive in the first quarter of 2016.

Until next time, Rob….
